18 Way Female Automotive Connector Housing – MCP 2.8 Grey

The 18 Way Female Automotive Connector Housing provides a durable and dependable connection for automotive wiring looms, vehicle electrical systems and commercial vehicle installations.

Designed to accept 18 female MCP 2.8 crimp terminals across three rows, this grey housing features keyed alignment and an integrated locking mechanism to help prevent incorrect mating or accidental disconnection.

Its glass-filled PBT construction provides excellent resistance to vibration and temperatures between -40°C and +120°C. Suitable for 12V and 24V applications in cars, vans, HGVs, trailers, plant machinery and industrial equipment.

Key features

• 18-way female automotive connector housing
• Accepts MCP 2.8 female crimp terminals
• Three-row terminal arrangement
• Strong glass-filled PBT construction
• Integrated latch-lock mechanism
• Keyed mating alignment
• Straight 180° cable exit
• Free-hanging cable mounting
• Supports wire-to-wire connections
• Suitable for 12V and 24V vehicle systems
• Operating temperature from -40°C to +120°C
• Designed for high-vibration environments
• Unsealed connector housing

Specifications

• Connector type: Female automotive housing
• Number of ways: 18
• Terminal type: Female receptacle
• Terminal size: 2.8mm
• Number of rows: 3
• Colour: Grey
• Terminal pitch: 5mm
• Row spacing: 5.5mm
• Cable orientation: Straight / 180°
• Housing material: Glass-filled PBT
• Operating voltage: Up to 28V DC
• Voltage systems: 12V and 24V
• Dimensions: 36 × 36 × 24mm
• Connection type: Wire-to-wire
• Mounting: Cable mount / free hanging
• Sealed: No

Connector housing only. Crimp terminals, secondary locking components and mating housings are supplied separately unless stated otherwise.

Please note: Picture is for illustration purposes only. Colour may vary.
